Extreme High Load Actuators, Piezo Linear Translators, Closed-Loop Control Option

  • High Force Piezo Actuators
  • Displacement to 120µm
  • Pushing Forces to 12500N (2750lbs)
  • Pulling Forces to 2000N
  • Sub-msec Response
  • Sub-nm Resolution
  • Options: UHV, Low & High Temperature, Water Protected

These very high load linear actuators are driven by a high-performance piezo stack and can handle loads to 2750 lbs. (1250kg) while providing nanometer precision motion. The linear actuators can be used in both dynamic and static mode. They provide sub-millisecond response and sub-nanometer resolution. The high load capacity and internal spring preload makes them ideal for machining applications and vibration cancellation.

Standard high load actuators can be run in open loop mode, providing very high resolution. When the highest repeatability, absolute accuracy, and precision are required, the P-177.10 closed-loop control option with ultra-high resolution strain gauges for position feedback operation with high performance PI servo controller electronics is recommended.

P-246 linear actuator models are equipped with special ceramic layers, providing more displacement in the same package compared to the than P-242 piezo stack models. On the other hand, their maximum operating voltage is limited to -1000 V with voltages in excess of -750 V recommended only for short periods of time.

The P-246.xx, P-242.30, and P-242.40 actuators are protected by a stainless steel case with internal spring preload, to keep pulling forces from the Piezo stack. The linear actuators P-242.10 and P-242.20 are encased with an aluminum case and equipped with stainless steel end pieces and spring bolts providing the preload.

Application examples:
Out-of-round machining, laser optics turning, precision machining, adaptive mechanics, vibration cancellation, smart structures, static and dynamic positioning of heavy parts, force generation for bending or compressing of material, etc.

Factory Installed Options: 1)
P-177.10 Closed Loop Option

P-702.10 High Temperature Option

P-702.20 Low Temperature Option

P-703.20 High Vacuum Option

P-705.00 Positive Polarity

P-706.xx Water Protected Case (not for P-242.10 and P-242.20)

1) When ordering the following options, change the last digit to 7, e.g. P-242.10 to P-242.17, and list options separately.

P-242, P-246 High Force Linear Actuators, Closed-Loop Option, (Piezo Linear Translators)

TECHNICAL DATA: P-242, P-246

Models *

P-242.10

P-242.20

P-242.30

P-242.40

P-246.20

P-246.30

P-246.50

P-246.70

Units

Notes

Open loop travel @ 0 to -1000 V

10

20

40

60

20

40

80

120

µm ± 20 %

A4

* Closed loop travel ³

10

20

40

60

20

40

80

120

µm

A5

* Integrated feedback sensor

SGS

SGS

SGS

SGS

SGS

SGS

SGS

SGS



B

* Closed / open loop ** resolution

0.2 / 0.1

0.4 / 0.2

0.8 / 0.4

1.2 / 0.6

0.4 / 0.2

0.8 / 0.4

1.6 / 0.8

2.4 / 1.2

nm

C4

Stiffness

1100

600

320

215

1050

560

295

200

N/µm
± 20 %

D1

Force generation (blocked)

11000

12000

13000

13000

21000

22000

24000

24000

N ± 20 %

D2

Push/pull force capacity

12500 / 2000

12500 / 2000

12500 / 2000

12500 / 2000

12500 / 2000

12500 / 2000

12500 / 2000

12500 / 2000

N

D3

Torque limit (at tip)

1000

1000

1000

1000

1000

1000

1000

1000

mNm

D6

Max. operating voltage

-1500

-1500

-1500

-1500

-1000

-1000

-1000

-1000

V

A7

Electrical capacitance

180

360

666

900

613

1150

2200

3280

nF ± 20 %

F1

Dynamic operating current coefficient (DOCC)

22

22

22

22

38

38

38

38

µA/(Hz x µm)

F2

Unloaded resonant frequency (f0)

11

8

4.5

3.5

8

6.5

4

3

kHz ± 20 %

G2

Standard operating temperature range

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

° C

H2

Voltage connection

VH

VH

VH

VH

VH

VH

VH

VH



J1

* Sensor connection

L

L

L

L

L

L

L

L



J2

Weight without cables

280

360

720

830

540

600

720

830

g ± 5 %

K

Material case / end pieces

AL / N-S

Al / N-S

N-S

N-S

N-S

N-S

N-S

N-S



L1

Length L

41

62

114

141,5

53.5

70.5

114

141.5

mm ± 0.5

L2

Case type

A

A

B

B

B

B

B

B



L3

Recommended Amplifier/Controller

B, J

B, J

B, J

B, J

B, J

B, J

B, J

B, J



M

* Closed loop models require the P-177.10 option and are supplied with calibration data sheets.
** Noise equivalent motion with E-507 amplifier.
