- SearchP-080 PICMA® Stack Multilayer Ring ActuatorProduct Description Specifications Downloads Quote / Order
Multilayer stack actuators
Flexible travel range up to 30 µm. Round cross section for easy integration.
UHV-compatible to 10-9 hPa, no outgassing, high bakeout temperature.
PICMA® piezo linear actuators
Low operating voltage -20 to 100 V. Ceramic insulation. High reliability, long lifetime.
Different heights, fast mounting according to customer requirements. Variety of shapes. Precision-ground end plates for reduced tolerances
Fields of application
Industry and research. For laser tuning, microdispensing, life sciences.
Short Instructions PZ264PICMA® Multilayer Piezo Actuators: P-08x, P-88x, PD0xx, PD410, PL0xx, PL1xx, PICMA® Stack, PICMA® Chip, PICMA® Bender3.0.0 04/20203.0.0 04/2020
Ask for a free quote on quantities required, prices, and lead times or describe your desired modification. All products available online can be ordered directly.
Actuators with PTFE-insulated stranded wiresP-080.311PICMA® Stack multilayer ring actuator with inner hole, 5.5 µm travel range, OD 8 mm × ID 4.5 mm × L 8.5 mm, stranded wiresP-080.341PICMA® Stack multilayer ring actuator with inner hole, 11 µm travel range, OD 8 mm × ID 4.5 mm × L 16 mm, stranded wires
Actuators with solderable contactsP-080.310PICMA® Stack multilayer ring actuator with inner hole, 5.5 µm travel range, OD 8 mm × ID 4.5 mm × L 8.5 mmP-080.340PICMA® Stack multilayer ring actuator with inner hole, 11 µm travel range, OD 8 mm × ID 4.5 mm × L 16 mm
