V-273 PIMag® Voice Coil Linear Actuator

High Dynamics and Inexpensive

V-273 PIMag® Voice Coil Linear Actuator
Product Description Specifications Downloads Quote / Order
  • Travel ranges to 20 mm
  • Velocity to 100 mm/s
  • Integrated linear encoder, 0.01 µm resolution
  • Optional force sensor with 1 mN resolution

PIMag® Voice coil

Voice coil drives consist of 2 essential components: A permanent magnet and a coil, which is located in the air gap of the magnetic field. When current flows through the coil, it moves in the magnetic field of the permanent magnet. The direction of motion depends on the polarity. Thanks to their low weight and friction-free drive principle, voice coil drives are particularly suitable for applications, which require high dynamics and high velocities at limited travel ranges. High scan frequencies and precision positioning are also possible with these drives, because they are free of the effects of hysteresis.

Highly accurate position measuring with incremental encoder

Noncontact optical encoders measure the position directly at the platform with the greatest accuracy. Nonlinearity, mechanical play or elastic deformation have no influence on the measurement.

Fields of application

OEM drives in automation. For fast handling tasks and precision positioning in the micrometer range, micromanipulation. Testing of force-sensitive switches and surfaces.

Specifications

Datasheet

Datasheet V-273

Version / Date
2019-05-15
Version / Date
2019-05-15
Version / Date
2019-05-20
Document language
pdf - 275 KB
pdf - 278 KB
pdf - 899 KB

Downloads

Datasheet

Datasheet

Datasheet V-273

Version / Date
2019-05-15
Version / Date
2019-05-15
Version / Date
2019-05-20
Document language
pdf - 275 KB
pdf - 278 KB
pdf - 899 KB

Documentation

Documentation

Short Instructions MP162EK

V-27x PIMag® Linear Actuators
Version / Date
1.0.0 2017-05-15
Document language English
pdf - 795 KB
Documentation

User Manual MP155

V-273.440 and .441 PIMag® Voice Coil Linear Actuators
Version / Date
1.1.2 2019-04-15
Version / Date
1.1.2 2019-04-15
Document language
pdf - 673 KB
pdf - 693 KB

3-D Models

3-D Models

V-273 3-D model

Quote / Order

Ask for a free quote on quantities required, prices, and lead times or describe your desired modification. All products available online can be ordered directly.
