P-603 Inexpensive PiezoMove Linear Actuator

Friction-Free Guides and Travel Ranges to 0.5 mm

  • Flexure guides for linear motion with minimum tip and tilt
  • Travel ranges to 500 µm
  • Optimized design for manufacturing in large quantities
  • Available with integrated position sensors
  • Outstanding lifetime due to PICMA® piezo actuators
  • Ideal for OEM applications in optics, medical technology, biotechnology, and microfluidics
  • Customized versions with longer travel range, shorter response time or nonmagnetic
P-603 Inexpensive PiezoMove Linear Actuator
Product Description Specifications Downloads Quote / Order

Application fields

  • Nanopositioning
  • High-speed switching
  • Patch clamp
  • Microdispensing
  • Adaptive systems technology / automation
  • Photonics / integrated optics
  • Biotechnology

Outstanding lifetime thanks to PICMA® piezo actuators

The PICMA® piezo actuators are all-ceramic insulated. This protects them against humidity and failure resulting from an increase in leakage current. PICMA® actuators offer an up to ten times longer lifetime than conventional polymer-insulated actuators. 100 billion cycles without a single failure are proven.

High guiding accuracy due to zero-play flexure guides

Flexure guides are free of maintenance, friction, and wear, and do not require lubrication. Their stiffness allows high load capacity and they are insensitive to shock and vibration. They work in a wide temperature range.

Specifications

Datasheet

Datasheet P-603

Version / Date
2023-12-11
pdf - 637 KB
Version / Date
2023-12-11
pdf - 643 KB
Version / Date
2019-07-31
pdf - 2 MB

Downloads

Product Note

Product Note

Product Change Notification Piezo Actuator Driven Products

Version / Date
2021-04-19
pdf - 377 KB
English

Datasheet

Datasheet

Datasheet P-603

Version / Date
2023-12-11
pdf - 637 KB
Version / Date
2023-12-11
pdf - 643 KB
Version / Date
2019-07-31
pdf - 2 MB

Documentation

Documentation

Short Instructions PZ302

PiezoMove® Linear Actuators: P-60x

Version / Date
1.1.0 2023-10-10
pdf - 633 KB
Version / Date
1.1.0 2023-10-10
pdf - 640 KB
Documentation

User Manual P603T0001

P-603 PiezoMove OEM Flexure-Guided, Lever-Amplified Actuators

Version / Date
2021-01-11
pdf - 631 KB
English

3-D Models

3-D Models

P-603 3-D model

zip - 70 KB

Quote / Order

Ask for a free quote on quantities required, prices, and lead times or describe your desired modification.

P-603.1S1

Inexpensive PiezoMove linear actuator; PICMA® piezo actuator drive; 100 µm travel range; SGS, indirect position measuring; bare wire strands; 0.5 m cable length

P-603.1S2

Inexpensive PiezoMove linear actuator; PICMA® piezo actuator drive; 100 µm travel range; SGS, indirect position measuring; LEMO connectors; 0.5 m cable length

P-603.3S1

Inexpensive PiezoMove linear actuator; PICMA® piezo actuator drive; 300 µm travel range; SGS, indirect position measuring; bare wire strands; 0.5 m cable length

P-603.3S2

Inexpensive PiezoMove linear actuator; PICMA® piezo actuator drive; 300 µm travel range; SGS, indirect position measuring; LEMO connectors; 0.5 m cable length

P-603.5S1

Inexpensive PiezoMove linear actuator; PICMA® piezo actuator drive; 500 µm travel range; SGS, indirect position measuring; bare wire strands; 0.5 m cable length

P-603.5S2

Inexpensive PiezoMove linear actuator; PICMA® piezo actuator drive; 500 µm travel range; SGS, indirect position measuring; LEMO connectors; 0.5 m cable length
