OEM Systems | Precision Components | Automation Sub-Systems
PI has a long track record of working with OEMs in the most demanding industries from Semiconductor Technology to Medical Design – industries where product performance, quality, and the ability to ramp up quickly are not the only parameters required to satisfy the customer's demands. Working with technology leaders all around the world forces you to continuously improve your yield, process, and product performance. And unless your quality is outstanding, you cannot become a key supplier to major US, European, and Japanese companies in the Optics, Photonics, Semiconductor, and Automotive industry.
Precision Automation Solutions | Engineered Systems
PI is a supplier of high-end precision motion systems and makes use of own drive components and high-precision positioners to build customized positioning and automation sub-systems —“motion engines”—for our customers. With the largest portfolio of precision motion technologies in the industry, PI engineers have the best foundation to find a solution that matches your requirements in terms of precision, quality and budget – in a timeframe that works for you.
Select the product type specified by the axes of motion required. Selection of more criteria expands or shortens the list of results. Select more than one filter at at time, for example, to find positioning stages designed for higher load capacity, too.
Air bearings provide advantages over mechanical bearings when vibration-free motion is required, highly constant velocity control is crucial, and when angular repeatability and geometric performance must be optimal. Air bearing stages (linear, rotary, and spherical) replace mechanical contact by a thin air film, avoiding wear, friction, vibration, and hysteresis effects.
Compact positioning stages are crucial for the miniaturization process in cutting-edge research and industrial applications, for test & measurement, optical and opto-mechanical alignment, and component assembly. PI provides the largest portfolio of miniature stages, including high-speed linear motor stages, economical stepper motor units, and ultra-compact piezo motor positioners.
PI offers the broadest and deepest range of precision motion technologies for micro and nano precision applications. Our engineers work with our customers to find the best drive and bearing technology for each individual application. Having access to multiple drive and positioning technologies allows an open discussion with a better outcome for the customer.
The PI group employs over 1,200 people in 15 countries and runs engineering and manufacturing centers on 3 continents. Select from the broadest portfolio of precision motion technologies, including piezoelectric and air bearing systems, with 1,000’s of standard products or have our engineers provide you with a custom solution.
A precision linear actuator is a positioning device that provides motion in 1 degree of freedom. PI designs and manufactures a variety of precision linear actuators (pushers) including economical stepper-motor driven actuators, high-speed linear motor types for automation and nanometer precise piezo-motor actuators.
A gantry precision positioning stage is sometimes called a linear robot or Cartesian robot. Gantries typically provide motion in 2 or 3 linear degrees of freedom (X-Y and X-Y-Z) and are often used for pick and place applications, 3D printing or laser machining, and welding applications.
Hexapod positioners are often referred to as Stewart Platforms. A hexapod is based on a 6-axis (XYZ, Pitch, Roll, Yaw) actuator system arranged in parallel between a top and bottom platform. PI parallel kinematics (PKM) precision positioning systems have many advantages over serial kinematics stages, such as lower inertia, improved dynamics, smaller package size and higher stiffness. In addition hexapods are more flexible than conventional 6 axis positioners.
Nanometer Precision: Nanopositioning Basics Tutorial. Piezo Nanopositioners, Scanning Stages, Flexure Guided Positioners | PI USA
There are several ways to achieve nanometer precision motion. The best positioning systems avoid friction all together, in both the drive system (motor) and in the guiding system (bearings). Frictionless bearings also avoid the bearing rumble caused by balls and rollers and provide vibration-free motion with highly constant velocity.
Piezo Motors | Linear Motor Positioners | Manufacturer
Piezo Motors are intrinsically vacuum compatible, non-magnetic and self locking at rest, providing long travel compared to traditional piezo mechanisms. The individual drive concepts are optimized for different applications, they differ in their design, size, cost, force & speed and other performance parameters.
Why All Piezo Motors are NOT Created Equal: The piezoelectric effect for precision motion control - PI Physik Instrumente.
The demand for higher speed and/or precision in fields such as bio-nanotechnology, semiconductors, metrology, data comm, and photonics keep pushing manufacturers to come up with innovative drive technologies.
Piezoelectric translators (transducers) are precision ceramic actuators which convert electrical energy directly into linear motion with high speed, force and virtually unlimited resolution. These actuators are used in every modern high tech field from semiconductor test & inspection to super-resolution microscopy, bio-nanotechnology and astronomy/aerospace technology.
Value Added Piezo Assemblies: Transducers, Actuators, Sensors, Manufactured by PI Ceramic
Developing and manufacturing piezo ceramic materials and components are complex processes. PI Ceramic - PI’s piezo material design and manufacturing facility - boasts several decades of experience as well as the right tools for rapid prototyping of custom engineered piezo components and assemblies. From the formulation of advanced piezo materials to the processing steps such as cutting, milling, grinding, and the precision assembly, every stage is controlled by our engineers and product specialists.
High Precision Microscope Stages, Piezo Lens Scanners, Tools for Bio-Imaging | PI-USA
Piezo nano-positioning stages are essential tools for high-resolution microscopy, such as Super Resolution Microscopy or AFM. Their sub-atomic resolution and extremely fast response allow researchers to create higher-quality images faster. PI provides a large variety of fast Z-Stages and collar piezo objective positioners for 3D imaging (Z-stack acquisition), deconvolution, and fast focusing applications.
Active Photonics Alignment | Optics Alignment | Solutions
PI provides a variety of innovative fiber alignment systems from motorized fiber positioners to automated optic and photonic alignment such as used in telecommunication, data commumication and for packaging / automation. In addition to fiber-based applications, fast steering systems for free-space-optical communication are also available. Products range from motorized 6D micromotion alignment systems for industrial photonics automation, through ultra-fast piezoelectric scanning & alignment modules to modular devices with manual control for laboratory test setups. All motorized systems come with extensive software for easy setup and integration.
Vacuum / UHV Compatible Stages - Linear & Rotary Positioners for Vacuum, Wide Temperature Ranges | PI USA
PI miCos has extensive experience in the design and manufacturing of vacuum and high vacuum compatible precision optomechanical positioning equipment for low temperature and wide temperature ranges. We provide translation stages, vertical linear stages, rotation stages, XY stages and complex multi-axis positioning systems in vacuum spec.
A piezo controller or driver is used to control the motion of a piezo positioning device. There are open and closed loop controllers. Open-loop controllers are often referred to as piezo driver or even piezo power supply. Closed-loop controllers are divided in two basic types: analog-servo and digital servo controllers.
PI provides a large variety of hardware & software solutions for high precision motion control. Our portfolio spans from integrated compact single axis servo controllers / drivers, such as popular Mercury-class motion controllers, to complex multi-axis systems for parallel-kinematics positioners, such as hexapods.
Motion Control Software | Software Tools | Positioning Solutions
For LabView, C++, VB, Matlab, Image Acquisitiong Packages, NI DAC Cards, .....
PI provides high-level, robust, easy-to-use software tools for fast, seamless integration of motion systems into application control software.
Adapters and Cables for PI Precision Motion Components
Standardization is common with adapter plates and brackets, but we can create a custom accessory to fit your application system. PI products ship with the required cables. Customization is always an option.
Piezo scanners take care of fast, continuous scanning tasks, where durability, dynamics, and precision matter. The larger travel ranges are realized with XYZ combinations or 6-axis hexapods. Integrated routines make it possible to perform single-axis alignments up to complex, multi-axis fiber array positioning within the shortest possible time.
PI offers a wide range of motorized linear stages to supply high-precision industrial markets like semiconductor and photonics, as well as high-end research. Vacuum versions are available for a large number of different models. Multi-axis compositions can be set up with adapter brackets or specialized vertical stages and compatible rotation stages.
Rotation stages with piezomotor make for particularly compact sizes. These compact rotation stages can be used in optics applications, where they position, for example, filters reliably and with excellent repeatability. Rotation stages can be mounted on linear stages without adapter and allow for flexible combinations of multi-axis positioning systems.
Piezoelectric ultrasonic transducers are available in a wide range of shapes like disks, plates or tubes, and different performance levels. They can be adapted to application requirements by using different piezoceramic materials, electrodes, and assembling technology.
PiezoWalk® actuators are highly specialized piezobased drives intended for integration. Designed for use in the semiconductor industry, they boost on reliability, position resolution and long-term stability. Their special features include minimum size with high force generation. The drive itself is resistant to magnetic fields.
PI offers stages with all kinds of motorization and guiding options: air-bearing, torque motor driven, motorized worm-gear coupled, tiny piezomotor stages and specialized goniometer stages with orthogonal tip-tilt mounting option.
Voice Coil Actuators with High Dynamics & Force Control Option
Voice coil drives show very high velocities and allow for fast step-and-settle. Wear-free flexure guidings or mechanical guidings are available. The optional force control allows for stand-alone solutions in pressure-sensitive device testing.
Stability, precision and dynamics are crucial in the application fields of PI’s XY stages. They are the basis of high throughput rates and reliable operation. PI makes use of own developments in the fields of PIMag® magnetic linear motors and PIglide air bearings. Industrial production and quality control benefit from PI’s high-load XY stages and planar scanners.
High-precision 2-axis nanopositioning systems integrate PICMA® piezo actuators for maximum reliability. Repeatable, drift-free positioning with optimal stability is possible by the use of high-quality nanometrology sensors.
PI Blog / Tech Articles on Advancements in Precision Motion Control, Automation and Piezo Technology | PI USA
PI’s tech blog offers 50 years of insight into innovative applications of precision motion control, nanopositioning, and micropositioning in industry, science, and research. We hope the PI blog is an enjoyable and informative resource, and a starting-point for innovation across disciplines.
PI provides high-level, robust, easy-to-use motion control software tools for fast, seamless integration of motion systems into application control software. Supported programming languages and applications include LabView, C++, VB, Matlab, Image Acquisitioning Packages, NI DAC Cards, ...
PI’s tech blog offers over 40 years of insight into innovative applications of precision motion control, nanopositioning, and micropositioning in industry, science, and research. We hope the PI blog is an enjoyable and informative resource, and a starting-point for innovation across disciplines.
Technologies and Applications for Precision Motion Components and Sub-Systems | PI USA
PI products are often used at the cutting edge of technology. They solve critical motion problems in lithography, microscopy, astronomy, laser technology, photonics and semiconductor manufacturing on locations around the world and in places as remote as the Science Lab on the Mars Rover.
Talk to our engineers first. They have access to in-depth knowledge and test data on diverse driving and guiding technologies, spanning from electromagnetic to piezoceramic and from mag-lev to air bearings. They also have experience selecting the right technology for each individual application. Often an adaptation of existing technologies/products will suffice to solve a problem. However, experience along with detailed knowledge and PI’s significant R&D investment in new technologies enables our engineers to take unique approaches.
