Hexapod, High Speed

New Hexapod 6-Axis Positioning Stage

The new H-811.S11 high-speed miniature hexapod, 6-axis stage, a faster version of the popular H-811 compact hexapod provides dynamic performance with bandwidth up to 25 Hz. The hexapod motion controller has an integrated wave form generator and facilitates high-speed multi-axis motion and jitter simulation applications such as employed in image stabilization testing.

Motion Controller & Motion Software
PI hexapod 6-axis stages are very easy to use and integrate. A dedicated C-887 hexapod motion controller and an extensive motion software package is available. Motion is commanded in directly in Cartesian coordinates. The selection of an arbitrary, pivot point is via one software command (important for alignment applications). In addition, the digital controller supports a LabVIEW-based software environment. The integration in text-based programming languages under Microsoft Windows or Linux is simplified by program libraries and exemplary codes.

Hexapod Simulation tools and virtual hexapod software is included. They can be made available in advance. This way, the virtual Hexapod can be tested and integrated in the customer before delivery to save valuable time.

More information on the C-887 Controller for Hexapod Positioning Systems.
