Category: Photonics

History and Future of Photonics Alignment Automation, Test & Assembly of SiP Components

From Electronics to Photonics The first computer link using optical fibers was commissioned four decades ago to safeguard communications from electromagnetic interference at the Cheyenne Mountain strategic command center [1]. Since then we have seen broad adoption of photonic communications technologies in an unfolding pattern of consistently diminishing physical scale: As a replacement for costly […]

Parallelism in Photonics Alignment Automation: Key to Economic Test & Packaging

Compared to the devices typical of the telecom revolution of two decades ago, today’s typical Silicon Photonics (SiP) devices present more channels, smaller form factors, and exponentially higher production quantities. Transverse alignment tolerances well below 50nm are common, and multi-channel inputs and outputs necessitate at least an additional theta-Z alignment in order to optimize and […]

Nanopositioning stages help create and characterize laser-written waveguides inside silicon

The future of computing and data communications will rely on a combination of optics and electronics. Silicon photonics circuits are gaining in importance; new techniques and tools for test and production of SiP related technologies are being researched and developed around the world. Direct laser writing of waveguides deep inside the bulk of monolithic crystalline […]

Fast Optical Alignment for SiP Production

Industry-leading speed and capability is an enabler for “photonomics” from wafer to packaged device;  2016 R&D 100 award winner! Problem The convergence of photonics and semiconductors promises a leap in data throughput, parallelism and energy efficiency. Design and materials challenges have by now been addressed. Practicalities of testing and packaging have not. Test and packaging […]

Stacks of Single Axis Stages vs. Hexapods

When faced with a multi-axis motion application, many users stack motion stages, and in fact that is a fine approach for assemblies of just a few axes. But as applications become more complex, so do the equivalent stacks-of-stages, and very real and practical considerations begin to come into play. Stiffness.  Some stage manufacturers publish stiffness […]

Silicon Photonics Test and Alignment

The need for higher performance computing and data-communication speed has led to the advent of silicon photonics. In addition, to higher performance, silicon photonics can also reduce the power requirements of next generation server farms significantly. Challenges With the advantages, this new technology also brings about several production challenges, including the need for test platforms […]
